Air-cooled Pre-cooler

Compressed air aftercooler has air-cooled type and water-cooled type. Aftercooler can reduce the inlet air temperature by an air-to-air exchanger with fan motor, or by an air-to-water exchanger with special tube. The air-cooled type operation cost is low, but the air-to-air exchanger is dependent largely on the ambient temperature. The water-cooled type has highly efficient, and the air-to-water exchanger needs cooling water.

Air-cooled Pre-cooler

1. 风冷型
型号	YD-1F	YD-2F	YD-3F	YD-6F	YD-10F	YD-15F	YD-20F	YD-30F	YD-40F

空气处理量Nm3/min	1	2	3	6	10	15	20	30	40
电源V	220

进气压力Mpa	0.2~1.4,1.4~8.0

进气温度℃	≤120
出气温度℃	≤45
环境温度℃	≤35
风机马达W	90	90	90	120	180	2x90	2x120	4x90	4x120

空气接口管径	3月4日	1’’	11/2’’	11/2’’	2’’	21/2’’	21/2’’	3’’	4’’
